MRP Series FRP Multi High Flow Filter Cartridge Housing
MRP Series FRP Multi High Flow Filter Cartridge Housing MRP Series FRP Multi High Flow Filter Cartridge Housing MRP Series FRP Multi High Flow Filter Cartridge Housing
MRP Series FRP Multi High Flow Filter Cartridge Housing MRP Series FRP Multi High Flow Filter Cartridge Housing MRP Series FRP Multi High Flow Filter Cartridge Housing

MRP Series FRP Multi High Flow Filter Cartridge Housing

Description

MRP Series FRP Multi High Flow Filter Cartridge Housing adopts the method of installing multiple large flow filter elements in cartridge housing to realize the need for greater flow in the water treatment system. FRP multi cartridge housing has the characteristics of longer service life, larger flow rate, good dirt capacity and high filtration efficiency, and is suitable for occasions where stainless steel filter housing cannot be used.

FRP multi high flow cartridge housing is easy to install and maintain, can help save a lot of space and equipment costs, so as to achieve cost-effective filtration. Because of FRP cartridge housing is strong corrosion resistance, high temperature resistance and high strength, it is widely used in seawater desalination, industrial RO pre-filtration, food and beverages, power plant, petrochemicals, industrial water treatment etc.

Specification
Housing MaterialFRP (Fibre Reinforced Plastic)
Housing DirectionVertical
Cartridge Length20", 40", 60"
Number of Cartridges4pcs
Installed Filter TypeHigh Flow Filter Cartridge OD 6"
Filtration Rating1μm - 100μm
ConnectionSide Port
Inlet/OutletDN125
Sealing TypeSwing Bolt Hinged
Seal MaterialEPDM, Buna-N, Viton, Silicon


Feature

● Easy installation and low maintenance cost, cost-effective and saving labor

● Save a lot of space and equipment costs, so as to achieve cost-effective filtration

● Longer service life, larger flow rate, good dirt capacity and high filtration efficiency

● According to the flow rate requirements, FRP multi high flow cartridge housing can be customized

● FRP cartridge housing is strong corrosion resistance, high temperature resistance and high strength


Application

● Power Plant

● Pretreatment

● RO Prefiltration

● Microelectronics

● Water Treatment

● Food and Beverage

● Sea Water Desalination


Performance

Operation Data for FRP Multi High Flow Filter Cartridge Housing

Max. Temperature80°C
Max. Pressure150 PSI
Liquid Flow DirectionSide in and side out
Flow Rate4 Round of 20" length: 60m³/h
4 Round of 40" length: 120m³/h
4 Round of 60" length: 180m³/h


Tech Support

FRP Multi Cartridge Housing for 4pcs 40" High Flow Cartridges


● FRP multi high flow cartridge housing can be desinged according to the flow rate requirements

● FRP multi high flow cartridge housing is large flow rate, up to 120m³/h, easy to install and maintain

● Strong dirt holding capacity and high filtration efficiency, longer service life & lower energy consumption

● Suitable for water filtration systems that cannot use stainless steel filter housing, greatly saving user costs


FRP Multi High Flow Filter Housing Production Lines



Order Information
MRPFilter LengthRound (No. of Filters)O-ring Material

MRP Series

FRP Multi High Flow

Filter Cartridge Housing

20 = 20"4 = 4 RoundE = EPDM
40 = 40"B = Buna-N
60 = 60" V = Viton
Silicon

For Example:

MRP-40-4-E

MRP Series FRP Multi High Flow Filter Cartridge Housing - 40" - 4 Round - EPDM

If need more larger flow rate, can combine FRP high flow cartridge housing, welcome to discuss and customize
